Yocto-PWM-Rx

€56.75
Tax excluded 3-5 days

That isolated device can decode PWM signals. It can be used as a pulse counter as well. You can add Ethernet, Wireless or GSM connectivity to this device.

Quantity
In stock

The Yocto-PWM-Rx is a 2 channels PWM input. Each channel can report frequency, duty cycle, and pulse length. It works from 0.05Hz to 250Khz and accepts any -30..+30V signal as long as it crosses the 0.7V threshold.

Each channel also features a pulse counter linked to a time counter. This allows to integrate over time the output of sensors such as flow-meters. The pulse counter works from 0 to 250kHz.

The two PWM inputs are galvanically insulated from the USB bus. This will allow you to connect the Yocto-PWM-Rx to main-powered equipments without risking to fry your computer.

This device can be connected directly to an Ethernet network using a YoctoHub-Ethernet, to a WiFi network using a YoctoHub-Wireless-g, it can even be connected to a GSM network thanks to the YoctoHub-GSM.

USB cables and enclosure to be ordered separately.

* *
YPWMRX01

Data sheet

Width
20mm
Length
54mm
Weight
7g
USB connector
micro-B
Channels
2
Refresh rate
50Hz
USB bus insulation
1kV
Input impedance
110KΩ
Max working voltage
-30 ... +30V
Threshold voltage
0.7V
Frequency
0.05 ... 250'000Hz
Normal operating temperature
5...40°C
Extended operating temperature
-30...85°C
Supported Operating Systems
Windows (PC + IoT), Linux (Intel + ARM), macOS, Android
Drivers
no driver needed
RoHS
Yes
Suggested enclosure
YoctoBox-Long-Thick-Black
Made in
Switzerland
*
