Yocto-Knob

€31.34
Tax excluded 3-5 days

This USB module can read up to five push buttons, potentiometers or resistive sensors (photodiodes, etc) You can add Ethernet, Wireless or GSM connectivity to this device.

Quantity
In stock

The Yocto-Knob device provides easy reading of 5 input buttons, contacts, switches or potentiometers (knobs) from USB. It is a kind of USB analog-to-digital converter (adc). It can also be used to read any analog resistive sensor, such as photodiodes.

On the device, 5 tiny LEDs constantly show the value of the 5 inputs, and 5 micro-switches connected in parallel to the inputs simplify the testing of your project.

This device can be connected directly to an Ethernet network using a YoctoHub-Ethernet, to a WiFi network using a YoctoHub-Wireless-g, it can even be connected to a GSM network thanks to the YoctoHub-GSM.

USB cables and enclosure to be ordered separately.

* *
YBUTTON1

Data sheet

Width
20mm
Length
45mm
Weight
5g
USB connector
micro-B
Channels
5
Refresh rate
250Hz
Normal operating temperature
5...40°C
Extended operating temperature
-30...85°C
Supported Operating Systems
Windows (PC + IoT), Linux (Intel + ARM), macOS, Android
Drivers
no driver needed
RoHS
Yes
Suggested enclosure
YoctoBox-Short-Thick-Black
Made in
Switzerland
*
